Operating Voltage Range:230Vac – 480 Vac, 3-phase
Nominal Input Current (AC):14 Amps
Root Mean Square Input Frequency (AC):47-63 Hz
Input Voltage (AC):120 – 240 Vrms, 1-Phase
Bus Overvoltage Protection:810V dc
Continuous Output Power @ 480 VAC:10.0 kW
Continuous Output Power @ 230 VAC:5.0 kW
Peak Output Current:94A
Shunt Voltage:800V dc
Indexing Feature:Advanced for superior machine control
PWM Frequency Input:Variable for precise speed control
EMC Compliance:Certified to meet various standards
Relative Humidity Range:0-95% non-condensing
Temperature Range:0°C to 55°C
The Allen-Bradley 2098-DSD-HV220-SE AC Drive is a robust, high-performance solution designed to meet the stringent demands of modern industrial automation. Its intelligent design supports contemporary integration and configuration methods, ensuring seamless integration with existing systems.
With a wide input voltage range and a choice of auxiliary power supply, this drive offers unparalleled flexibility and reliability. It boasts a nominal input current of 14 Amps and a frequency range of 47-63 Hz, making it suitable for a variety of applications.
Featuring a continuous output power capacity of 10.0 kW at 480 VAC and 5.0 kW at 230 VAC, the 2098-DSD-HV220-SE ensures high efficiency and performance across different operational scenarios. Its advanced indexing feature enhances machine control, delivering superior performance and accuracy.
Equipped with a 20 Ohm internal shunt resistance, the drive ensures stable operation under varying conditions. It is designed for use within a temperature range of 0°C to 55°C, ensuring reliable performance in diverse industrial environments.
The Allen-Bradley 2098-DSD-HV220-SE is certified to meet multiple drive standards and adheres to EMC directives, ensuring compliance and reliability. This high-voltage AC drive is a standalone solution for various industrial applications, offering a comprehensive set of power platforms, connectivity options, and functions.
